News

Electric Chain Hoist: Revolutionizing Heavy Load Handling in Confined Spaces

In industrial environments such as factories, warehouses, and equipment maintenance areas, space constraints often hinder traditional lifting equipment due to their bulky size and cumbersome operation. The ​​electric chain hoist​​ (Electric Chain Hoist) addresses these challenges through targeted design, prioritizing ​​compact structure​​, ​​precision control​​, and ​​multi-layered safety​​, making it an efficient solution for confined-space handling. Below is a detailed analysis of its technical specifications and practical applications.     I. Structural Innovations for Spatial Adaptability​​   1.​​Low Headroom Technology​​   Traditional wire rope hoists require over 600 mm of vertical space for drum mechanisms. In contrast, electric chain hoists employ a ​​dual-trolley and motor integration design​​, reducing body height to 230 mm (for 2-ton models) and minimizing the hook-to-beam distance to 270 mm—saving 46% vertical space. For instance, in a warehouse mezzanine with 2.5 m ceiling height, it can lift a 1.8 m pallet to a 2.4 m shelf, whereas traditional equipment maxes out at 2.1 m due to headroom limitations.   2.​​Lightweight Body and Optimized Transmission​​   ​​Material Engineering​​: The housing uses ​​die-cast aluminum alloy​​ or high-tensile steel via thin-wall extrusion. A 1-ton model weighs only 45 kg, over 50% lighter than equivalent wire rope hoists. ​​Chain System​​: ​​Planetary...

What is a European type single girder overhead crane?

1. Core Definition & Design Philosophy   • Essence of “European-Style”: Signifies not origin labeling, but a design strictly adhering to European mechanical design standards (e.g., FEM, DIN, EN 13001 / EN 12077 series). • Core Design Philosophy: Efficiency, Energy Saving, Compactness, Safety. • Core Value Manifestations: ◦ Lightweight: Main girder weight 15%–25% lighter than comparable LDi types, significantly reducing wheel load (e.g., factory rail beam load typically reduced from 25 kN/m to 20 kN/m). ◦ Modular: Combines four core modules – End carriages, Triple-unit drives, Electric hoists, Electrical packages – in a “building block” fashion, dramatically shortening delivery times (typically 4-6 weeks). ◦ Total Cost of Ownership (TCO) Optimization: Although initial purchase cost is typically 20%-30% higher, high reliability and low maintenance lead to >25% lower TCO over 15 years.   2. System Structure Breakdown: Five Core Modules   2.1 Main Girder   • Structure: Partial rail box girder or reinforced H-beam (optimized height-to-width ratio 1.2–1.5). • Material & Process: ◦ Steel: Q355B or higher, passing -20°C low-temperature impact toughness tests. ◦ Manufacturing: CNC plasma cutting → Robot CO₂ welding → Vibratory stress relief → Shot blasting to Sa2.5 standard → ≥80μm epoxy zinc-rich primer. • Key Performance: Under...

Selling High-Quality Overhead Cranes

We provide robust, reliable, and cost-effective crane solutions. Call now for a free quote.   Welcome to WEIYING   WEIYING has 34 years of manufacturing experience and 12 years of export experience. Its business covers more than 100 countries and regions worldwide, including Asia, Europe, America, Africa, and Oceania, forming a global product sales network. It has obtained ISO system certification and CE product certification!   WEIYING provides robust, high-quality, and affordable crane solutions. We specialize in lifting solutions and overhead crane systems, and have trained a group of engineers with excellent technical skills. This helps ensure that the cranes you purchase from WEIYING are of better quality.   WEIYING offers a complete range of cranes and material handling equipment, including 6 series such as electric hoists, electric winches, gantry cranes, and overhead cranes, which can almost meet any application needs!   To improve your productivity, we also have a sales team specializing in the crane field, which can evaluate the difficulties you are currently facing and provide customized services to ensure that the cranes you purchase from WEIYING can meet your application site requirements!   E-mail: karida@weiyinglift.com Website: www.wycrane.com

Some little knowledge about end beams

End trucks are the transverse structures located at both ends of overhead crane bridges or gantry crane girders. They connect the main girders longitudinally, forming the crane’s rigid “I-beam” frame, and support the trolley travel mechanism for movement along tracks.   Core Components:​​   ​​Main Frame:​​ Typically a welded steel box-section (12-30mm plates) with stiffeners, providing high bending/torsional strength with optimal weight. ​​Travel Mechanism:​​ Consists of drive wheels (usually hardened cast or forged steel), axles, bearings, and housings. Larger wheel diameters reduce ground pressure. ​​Buffers:​​ Installed at both ends (common types: polyurethane, rubber, or hydraulic) to absorb impact energy at track ends. ​​Connection Points:​​ Interfaces (high-strength bolted or welded) to securely join the end truck to the main girders. Braking System:​​ Spring-applied, electrically released brakes stop travel motion reliably.     Key Functions:​​   Load Bearing:​​ Transfers the crane’s total load (self-weight, hoist unit, lifted load) from the girders to the tracks. Designed with safety factors ≥1.5 and deflection limited to span/800. ​​Travel Stability:​​ Wheel assemblies guide the crane precisely along tracks. Alignment is critical (parallelism ≤2mm/m, wheel verticality ≤1/1000). ​​Structural Connection:​​ Forms the rigid end frame, integrating main girders and travel drives. ​​Impact Absorption:​​ Buffers protect the crane and...
