A 5 ton overhead crane is one of the most widely used lifting solutions in light to medium industrial settings. With moderate lifting capacity, flexible configuration options, and adaptable structural design, this type of crane is suitable for workshops, warehouses, production lines, and maintenance facilities across different industries. This article provides a fully detailed overview of the types, features, applications, pricing factors, and real delivery cases to help global buyers make informed purchasing decisions.
Although 5 tons is a relatively standard lifting capacity, the structural design and operational performance of a 5 ton bridge crane can vary significantly depending on the installation environment, working cycle, and production demands. The following are the main types of 5 ton overhead cranes used in industrial applications:
This is the most widely used 5 ton crane type. The crane adopts a single-girder structure with a CD/MD wire rope hoist or a more advanced European-style hoist. The LD type provides excellent cost-performance ratio, making it suitable for general lifting operations such as machining, assembly, fabrication, warehousing, and routine material handling.
Compared with the traditional LD model, the HD European crane uses a compact modular design. Its hoist has lower headroom, which significantly increases lifting height and effective working area. It features smoother operation, lower noise, reduced energy consumption, and superior positioning precision. This type is ideal for workshops requiring frequent lifting cycles or high operational efficiency.
Although 5-ton cranes are typically single-girder, there are situations where a double girder bridge crane is preferred—such as workshops with longer spans, higher lifting heights, special lifting devices (lifting beams, magnets), or higher working class requirements. The double girder structure enhances rigidity, improves stability, and supports more customized attachments.
For high-tech production lines, precision machining, or continuous intensive lifting, the European double girder crane offers the highest performance, with frequency conversion control, intelligent monitoring, and smoother load handling.
All these crane types can be fully customized, allowing customers to achieve optimal performance based on their unique project needs.
A well-designed 5 ton bridge crane offers a combination of durability, stability, operational efficiency, and safety. Below are the core features that define a high-quality overhead crane:
Manufactured according to international standards such as FEM, ISO, and GB, the crane’s main beam and end beams are optimized using finite element analysis. This ensures enhanced structural strength, reduced deflection, and long-term reliability even in continuous-duty settings.
Depending on customer needs, the crane can be equipped with either a traditional CD/MD hoist or a high-performance European hoist.
CD/MD Hoist: Economical, reliable, widely used.
European Hoist: Smaller size, dual-speed or frequency-controlled lifting, smoother operation, and longer service life.
The crane and trolley traveling systems can use either soft-start motors or variable frequency drives (VFD). These allow for controlled acceleration, reduced load swing, excellent positioning, and improved safety.
Customers may choose pendant control, wireless remote control, or cabin control. Remote control is particularly suitable for complex or hazardous environments, ensuring the operator maintains a safe distance from lifted loads.
Safety features are essential for any lifting operation. A 5 ton crane typically includes:
Overload protection
Emergency stop switches
Limit switches for lifting and traveling
Buffer blocks and rail clamps
Phase-loss & voltage protection
Anti-collision systems (optional)
These devices minimize accidents and ensure stable working conditions.
The modular design of modern cranes makes assembly more convenient and reduces downtime. Major components are easy to inspect and replace, cutting long-term maintenance costs.
Span, lifting height, speeds, power supply, duty cycle, and beam structure can all be tailored based on factory layout and operational requirements.
The flexibility and moderate capacity of a 5 ton overhead crane make it highly adaptable to various industries. Its applications include:
Machinery manufacturing & assembly
Used for transporting motors, molds, mechanical components, and semi-finished products along production lines.
Metal fabrication & steel processing
Ideal for lifting metal plates, profiles, welded components, and steel structures.
Automotive & parts manufacturing
Widely used for handling stamping molds, engines, frames, and auto parts.
Warehouse & logistics
Used for loading/unloading and organizing inventory with efficient material flow.
Equipment maintenance workshops
Perfect for lifting pumps, compressors, and mechanical equipment during repair tasks.
Plastic molding factories
Often used for lifting molds and finished product handling.
Light manufacturing & electronics
Assists in safe and accurate movement of sensitive or precision components.
Small foundries and assembly plants
Provides reliable material handling in multi-process workflow environments.
Because of its reasonable price, wide adaptability, and ease of installation, the 5-ton crane remains one of the most frequently used equipment in global industrial projects.
The 5 ton overhead crane price can vary significantly depending on its design, configuration, and installation requirements. Here are the key factors:
LD cranes cost less, while HD European cranes have advanced components and higher precision, increasing the price. Double girder cranes are more expensive due to additional steel structure and higher performance.
Longer spans and higher lifting heights require more materials and stronger beams, directly affecting cost.
Higher duty cycles require better motors, enhanced steel structures, and more durable components.
European hoists with frequency conversion and precise control have a higher price compared to standard hoists.
High-speed operation, anti-sway systems, smart monitoring, and automation functions increase the overall cost.
Different countries require different voltages (380V, 415V, 220V, 440V, etc.), which may influence the selection of motors and electrical system pricing.
Existing building strength, runway beams, and on-site installation conditions also affect total project cost.
If you need a custom 5 ton bridge crane price, design support, layout drawing, or a professional engineering proposal, welcome to contact us for a tailored quotation.
 |
 |
Recently, a Filipino customer successfully installed and put into operation a 5 ton single girder overhead crane with an 18-meter span. The crane now supports daily material handling tasks in their production workshop.
Technical Parameters:
Load capacity: 5 tons
Span: 18 m
Lifting height: 8 m
Working grade: A5
Lifting speed: 8 m/min
Trolley travel speed: 20 m/min
Crane travel speed: 20 m/min
Power supply: 380V, 60Hz, 3-phase
Due to the customer’s high operational frequency, the crane was designed to meet Class A5 duty requirements, ensuring long-term reliability and stability.
At the beginning of the month, we shipped eight identical LD type 5 ton overhead cranes to a machinery manufacturing factory in the Philippines. These cranes have arrived at the destination port and will soon be installed in a mechanical parts production workshop.
Technical Specifications:
Span: 10 m
Lifting capacity: 5 tons
Lifting height: 9 m
Working duty: A3
Lifting speed: 8 m/min
Crane travel speed: 20 m/min
Voltage: 220V, 50Hz, 3-phase
All eight cranes were fully identical in structure and parameters, ensuring unified operation, easy maintenance, and efficient production management for the customer.
A 5 ton overhead crane is one of the most versatile and widely adopted lifting solutions in modern industrial facilities. Featuring customizable designs, strong lifting performance, stable operation, low maintenance costs, and compatibility with a variety of production environments, it continues to be a preferred choice for machinery manufacturing, assembly workshops, logistics centers, and metal fabrication plants.
Whether you require a standard single-girder model or a high-end European version, our engineering team can provide complete technical support, 2D/3D drawings, and a customized quotation that fits your factory layout and budget.
Q1: What is the typical price of a 5 ton overhead crane?
Prices vary depending on crane type, span, lifting height, hoist configuration, and working duty. Contact us for an accurate quotation.
Q2: Can a 5 ton bridge crane be installed in an existing workshop?
Yes. We design cranes according to your building dimensions and provide runway beam solutions if needed.
Q3: Do you offer custom designs for special lifting requirements?
Absolutely. We can customize lifting beams, magnets, hooks, grab buckets, and other attachments.
Q4: What is the delivery time for a 5 ton overhead crane?
Usually 15–35 days depending on production requirements and customization level.
Q5: Do you provide installation support?
We offer on-site installation guidance, engineer support, online installation instructions, and full after-sales service.
